INVT Solution for Edge Banding Machine in China

Exclusive reveal：A set of INVT electrical equipment to help you solve all the problems of the edge sealing.

1.Project background

Edge sealing machine equipment is one of the important equipment in the woodworking industry. So far, a variety of different types of edge sealing machines have been derived, of which fully automatic linear edge sealing machine at home and abroad has a number of manufacturers with mature solutions. The advantage of the fully linear automatic edge sealing machine is able to process a large number of plates with high efficiency, so the equipment has certain requirements for the work speed. At this stage, the equipment is not too difficult to reach the level of friendly business, but there are patent barriers.

2.Customer demands

A customer in Zhenjiang purchased a complete set of electrical equipment, including controllers, frequency converters, touch screens, etc., for a fully automatic linear edge sealing machine. The following are customer demands:

1.Realize fully automated solutions;

2.High process precision;

3.Increase working speed;

4.Simple operation.

3.INVT solutions

The advantage of GD20:

1.VS series HMI is equipped with industrial-grade high-performance Cortex-A8 processor, significantly improving data processing efficiency and faster response.

2.IVC1 micro-programmable controller has high speed processing capability, which can improve process accuracy and stability.

3.The compact structure of the GD20 saves installation space for customers.

In order to realize the customer's needs, INVT introduces the system solution of HIM+IVC1 micro programmable controller + Gooddrive20 series economic open-loop vector inverter. The solution is mainly for medium and large automatic linear edging machine, only able to seal the regular straight-edge panels.

4.Customer value

1. Fully automatic solution: Based on the existing mechanical equipment, the whole process is responsible for the scheme design, and the automatic edge sealing machine scheme is realized to save manpower and material resources.

2. Process precision: The method of recording the real time position of the plate eliminates the need for the alignment head, alignment tail and tracking sensors, and the error is controlled within 0.5 mm.

3. Working speed: Edge efficiency is high, edge sealing effect is stable, reach the standard level of the same industry.

4. Simple operation: Touch screen interface design is simple, fine tuning parameters in about 5, easy to operate.

5. Cost: The whole electrical system is provided by INVT. Centralized procurement effectively reduces the procurement cost and maintenance difficulty of equipment.

5.Concluding remarks

This paper mainly introduces the solution of INVT on automatic linear edge banding machine. The outstanding feature of this solution is that the encoder is used to replace the sensors in many places such as alignment head and alignment tail. At the same time, the key action of alignment head and alignment tail process is simplified, so as to save input cost for customers and improve the production efficiency of customers' equipment.

INVT has a high-quality technical support team, to provide customers with a steady stream of professional technical services, from electrical schematic design, product programming to equipment debugging, INVT provides professional technical support throughout the process, the technical service response is rapid, to ensure the stable operation of equipment, customer satisfaction for the purpose.
